Cerian Triac Smart Dimmer AC WiFi – 2.4G Push Battens
Triac Smart Dimmer WiFi
The Triac Smart Dimmer WiFi makes lighting control simple and convenient. It allows you to control compatible lights using a mobile app, RF remote or voice assistant.
As a result, you can upgrade compatible lighting without complex rewiring.
WiFi and 2.4G RF Control
The dimmer supports WiFi smartphone control for convenient everyday use. You can adjust your lights from your phone when connected to the supported smart system.
It also supports 2.4G RF remote control. The control range can reach up to 30 metres in open, barrier-free conditions.
In addition, the system supports voice control through compatible platforms such as Amazon Alexa and Google Home.
Smooth 0–100% Dimming
The dimmer provides smooth brightness adjustment from 0–100%. Therefore, you can set the light level to suit different times and activities.
The trailing-edge phase dimming system also supports comfortable lighting control. It is designed for flicker-free operation with compatible loads.
You can also adjust the minimum brightness level using the dedicated setting.
PUSH Switch Control
The dimmer supports a PUSH switch for simple manual control. A compatible push switch can turn the light on or off.
It can also provide continuous dimming control. This gives you another option when a remote or app is not required.
Built-In Safety Protection
Safety is an important part of the dimmer design. The unit includes several built-in protection functions.
The temperature detection system monitors operating temperature. If the unit becomes too hot, the protection system can activate and recover automatically.
The dimmer also includes overload protection. The automatic power-limit function helps protect the unit when the connected load is too high.
Wide Load Compatibility
The dimmer supports several types of compatible lighting loads.
It can control dimmable LED lights and Triac dimming LED power supplies. It also supports incandescent and high-voltage halogen lamps.
However, always check the load type and maximum power before installation.
Supported Loads
| Load Type | Maximum Output |
|---|---|
| Dimmable LED Light | 100W @ 110V / 200W @ 220V |
| Triac Dimming LED Power Supply | 100W @ 110V / 200W @ 220V |
| Incandescent & High-Voltage Halogen Lamps | 154W @ 110V / 308W @ 220V |
Compact Design
The dimmer measures only 49×49×24mm. Its compact size allows it to fit inside a standard 86×86 wall junction box.
Therefore, it can work well in new installations and retrofit projects.
The housing also uses V0 fire-retardant material for added protection.
Smart Lighting for Homes and Projects
This smart dimmer suits a wide range of lighting projects. For example, you can use it in homes, offices, retail spaces and other commercial environments.
It is especially useful when upgrading existing compatible lighting to smart control.
Recommended Applications
The Triac Smart Dimmer is suitable for:
- Smart home lighting
- Residential LED lighting
- Commercial lighting
- Retail lighting
- Hospitality projects
- Renovation projects
- Retrofit smart lighting
- Compatible dimmable LED fixtures
- Incandescent lighting
- High-voltage halogen lamps
Why Choose the Triac Smart Dimmer?
- WiFi smartphone control
- 2.4G RF remote control
- Voice assistant compatibility
- Smooth 0–100% dimming
- Flicker-free operation
- Trailing-edge phase dimming
- PUSH switch support
- Adjustable minimum brightness
- Overload protection
- Overheat protection
- Automatic recovery
- Compact 49×49×24mm design
- V0 fire-retardant housing
- Up to 30m RF control distance in open conditions
