Black Sensor PIR wall light

PIR Motion Sensor Wall Light Controller with adjustable 4–10m detection, 3–2000 LUX control, dusk-to-dawn mode, 10-second to 10-minute delay and IP54 protection. Home Mode provides 100% brightness on motion and 20% standby brightness.

You Save $2.69

Original price was: $14.78.Current price is: $11.83. (price_including_tax).

Inc.GST
Sale!

Additional information

Weight 0.10 kg
Dimensions 6 × 6 × 6 cm
Enquire Now Call: 02 8103 0048

PIR Motion Sensor Wall Light – IP54 Smart Sensor Controller

Adjustable Detection | Dusk-to-Dawn Mode | Energy Saving Lighting Control

Product Overview

The CE-B PIR Motion Sensor Wall Light Controller is a smart lighting solution designed to automatically control wall lights based on motion detection and ambient light levels. Built with advanced PIR sensing technology, the sensor improves energy efficiency while enhancing safety and convenience in residential and commercial environments.

Featuring adjustable sensitivity, delay time, and lux settings, this sensor allows precise customisation for different lighting applications including entrances, walkways, garages, and outdoor walls.

Key Features

PIR motion detection technology
Adjustable sensing distance (4–10 meters)
Dusk-to-Dawn automatic lighting mode
Adjustable delay time (10 seconds – 10 minutes)
Day/Night LUX control (3–2000 LUX)
Energy-saving Home Mode (100% → 20% brightness)
Manual override switch
IP54 weather protection
Easy wall installation

Smart Lighting Modes

Home Mode

  • Light turns 100% brightness when motion detected
  • After delay time, reduces to 20% standby brightness
  • Improves security while saving energy

Dusk-to-Dawn Mode

  • Automatically activates only at night
  • No operation during daytime
  • Fully automatic lighting control

Adjustable Controls

The sensor includes multiple adjustment knobs:

  • TIME: Controls lighting delay duration
  • SENS: Adjusts detection distance
  • LUX: Sets ambient light activation level
  • Manual Switch: Override automatic mode

Applications

Ideal for:

  • Residential entrances
  • Outdoor wall lighting
  • Garages & driveways
  • Pathways & corridors
  • Commercial buildings
  • Security lighting systems

Installation

  1. Fix mounting base to wall surface
  2. Connect L / N / Ground wiring terminals
  3. Select preferred color temperature (WW/NW/CW)
  4. Attach lamp body and restore power

⚠ Installation by certified electrician recommended.

Safety Notes

  • Turn OFF power before installation
  • Product must be grounded
  • Handle carefully during installation
  • Maintenance should be performed by qualified professionals
Parameter Specification
Product Type PIR Motion Sensor Wall Controller
Model CE-B Wall Sensor
Detection Technology Passive Infrared (PIR)
Input Voltage AC100–265V
Frequency 50/60Hz
Detection Distance 4 – 10 meters (adjustable)
Delay Time 10 sec – 10 min (adjustable)
LUX Control Range 3 – 2000 LUX
Operating Modes Home Mode / Dusk-to-Dawn Mode
Brightness Function 100% motion → 20% standby brightness
Installation Type Wall Mounted
IP Rating IP54
Color Temperature Control WW / NW / CW selectable
Application Indoor & Outdoor Covered Areas
Safety Requirement Grounded Installation Required

Additional information

Weight 0.10 kg
Dimensions 6 × 6 × 6 cm
0.0
Based on 0 reviews
5
0%
4
0%
3
0%
2
0%
1
0%
0 of 0 reviews

Sorry, no reviews match your current selections

30W LED Sensor Security Floodlight30W LED Sensor Security FloodlightBlack Sensor PIR wall light

Related products

The PIR Motion Sensor from Vesta Lines provides automatic lighting control for residential and commercial areas. It detects movement and ambient light levels to control connected wall lighting.

With an adjustable 4–10 metre detection range, 10-second to 10-minute delay, and 3–2000 LUX adjustment, you can set the sensor to suit different environments. In addition, the dusk-to-dawn mode activates lighting only when the ambient light level requires it.

The Home Mode increases the light to 100% brightness when motion is detected. After the selected delay, the light reduces to 20% standby brightness. Therefore, the sensor can help reduce energy use while maintaining useful background lighting.

The IP54-rated housing suits selected indoor and outdoor wall-lighting applications. A manual override also gives you more control when automatic operation is not required.

PIR Motion Sensor FAQ

What does the PIR Motion Sensor do?

The PIR Motion Sensor detects movement and ambient light to control compatible wall lighting automatically.

What is the detection range?

The detection distance can be adjusted from 4 to 10 metres using the SENS control.

Can I adjust the lighting delay?

Yes. The TIME control provides an adjustable delay from 10 seconds to 10 minutes.

What is the LUX adjustment range?

The LUX control can be adjusted from 3 to 2000 LUX.

Does the sensor have a dusk-to-dawn mode?

Yes. The dusk-to-dawn mode allows the lighting system to operate according to ambient light conditions.

What is Home Mode?

Home Mode activates the connected light at 100% brightness when motion is detected. After the selected delay, the light reduces to 20% standby brightness.

Can I manually override the sensor?

Yes. The sensor includes a manual override switch for additional lighting control.

Is the sensor suitable for outdoor use?

The sensor has an IP54 rating and suits selected outdoor wall-lighting applications when installed in an appropriate location.

Does installation require an electrician?

Yes. The installation involves L, N and Ground wiring. A qualified electrician should complete the installation and ensure the wiring and grounding meet applicable requirements.
